MAGNUM 7500 ADVANTAGES

The "Thermostat ready" Magnum 7500 fits your every need by allowing you to choose what heat setting works best for your home. Resulting in less wasted energy dollars.
The "Furnace with a view", Magnum 7500, gives you the flexibility of installing your furnace for your viewing pleasure. You will know how the unit is performing and when maintenance is needed.
We invented the "Self-cleaning Oxygenation Firepot" for corn burning. Our oxygenizing stirring system results in no need for clinker removal. You now can burn longer without shutting down your corn furnace, so your home will continue to be safe and warm.
The "ease of installation" will allow more locations for your furnace installation, along with saving a ton of money by not having to put up an additional chimney.
The Magnum 7500 is designed with the most "advanced heat exchangers" and "air distribution system" on the market today. This keeps the heat in your home not up the chimney. Along with the high-tech design, it allows close clearances to combustibles, making the Magnum 7500 one of the most versatile and space saving biomass/corn furnaces on the market.

Specifications

Heat Input* BTU output 75000 BTU

Fuel Storage Capacity 210 Lbs.

Width 26"

Height 47 ½"

Depth (includes ash lip) 36"

Shipping Weight 480 pounds

Electrical Requirements 115 volts - 60 cycle - 15 amp Circuit

Flue Size (rear exit) 4" Type L Vent

Warm Air Outlet 12" Round or 12" x 12" rectangular

Room Air Blower 1240 CFM furnace blower

Cold Air Return 14" x 24", 12" round

Filter Size 16" x 25"

Overall unit efficiency up to 87%

*BTU input will vary, depending on the brand of fuel, quality of fuel and moisture content. Consult your authorized Magnum 7500 reseller for information on the best fuel to use to get the best results.

MAGNUM 6500 ADVANTAGES

Revolutionary firepot design for extended burn times between cleaning - no fuel stirrer means less fly ash generation
No need to shut down furnace to remove clinker
No fuel stirrer to replace
The "Thermostat ready" Magnum 6500 fits your every need by allowing you to choose what heat setting works best for your home. Resulting in less wasted energy dollars.
The "Furnace with a view", Magnum 6500, gives you the flexibility of installing your furnace for your viewing pleasure. You will know how the unit is performing and when maintenance is needed.
The "ease of installation" will allow more locations for your furnace installation, along with saving a ton of money by not having to put up an additional chimney.
The Magnum 6500 is designed with the most "advanced heat exchangers" and "air distribution system" on the market today. This keeps the heat in your home not up the chimney. Along with the high-tech design, it allows close clearances to combustibles, making the Magnum 6500 one of the most versatile and space saving biomass/corn furnaces on the market.

Specification

Heat Input*BTU output is up to 65,000

Fuel Storage Capacity 190 Lbs.

Width 26"

Height 47 ½"

Depth (includes ash lip) 36"

Shipping Weight 560 pounds

Electrical Requirements 115 volts - 60 cycle - 15 amp Circuit

Flue Size (rear exit) 3" or 4" Type L Vent

Warm Air Outlet 12" Round or 12" x 12" rectangular

Room Air Blower 1240 CFM furnace blower

Cold Air Return 14" x 24", 12" round

Filter Size 16" x 25"

Overall unit efficiency up to 87%

*BTU input will vary, depending on the brand of fuel, quality of fuel and moisture content. Consult your authorized Magnum 6500 reseller for information on the best fuel to use to get the best results.

The Magnum 6500 and 7500 are house or shop furnaces capable of burning a wide variety of biomasses (corn, wheat barley, oats, peas wood pellets, etc). They can be attached to an existing duct work or as a stand alone installation.

They are rated at 65,000 and 75000 BTU max output
